Thickness : 6mm to 100mm
Width : 1,500mm to 2,500mm
Length : 6,000mm to 12,000mm
Production : Hot-Rolled (HR) / Cold-Rolled (CR)
Heat Treatment : N, Q+T
Surface Paint : EP, PE, HDP, SMP, PVDF
Material : Rockstar 500, Rockstar 500 Steel Plate, Rockstar 500 Abrasion Resistant Steel Plates, Rockstar 500 Wear Resistant Plates
ROCKSTAR 500 Plates
Rockstar 500 Abrasion resistant steel Plates, ROCKSTAR 500, Rockstar 500 plate, Rockstar 500 Wear Plates Exporters, Stockists and Suppliers in India.
Champak steel is a manufacturer, and traders of Rockstar 500 plates for a number of industries. Our products are developed using top-notch equipment that make them reliable.
Our Rockstar 500 plates are wear-resistant steel that provide a mixture of properties such as hardness, toughness, formability, weld-ability and surface finishing. Rockstar 500 plates find usage in mining and construction market. Some of the applications such as crushers, body liners for truck, hoppers, buckets, beds, chutes and conveyors use these Rockstar 500 products. The 500 Rockstar plates have good formability with less damage to hardness. We deliver a range of product to different industries in customizable options like size, thickness and finishing to meet customer centric demands.
Our customer base demands our products for their high-quality and durability in all kinds of usage. We deliver products that are quality checked and offer precise finishing.
Rockstar 500 BHN Plate, 500 HBW Rockstar plates, Rockstar 500 Low-Temperature Steel Plates Dealer, Rockstar 500 Liner Plates Distributors, Rockstar 500LT plates Stockholders in Mumbai.
Content
- Rockstar 500 Plates Specification
- Rockstar 500 Plates Chemical Analysis
- Rockstar EN 10051 Plate Mechanical Properties
- Rockstar 500 Steel Plate Makes
- Rockstar 500 BHN High Strength Plates Processing
- Rockstar 500LT Plate Available Sizes
- 500 HBW Rockstar Plates Available Thickness, Widths and Lengths
- Price List of Abrasion resistant Rockstar 500 Plate
- Hot Rolled and Cold Forming Rockstar 500 BHN Plates Application Industries
- Other Keywords For Rockstar 500 Plates
- Worldwide Distributors of Rockstar 500 Plates
ROCKSTAR 500 Plates Specification :
Chemical Composition Of Rockstar 500 Plates
| Rockstar 500 Chemical Composition (%) | |||||||||||
| Plate thickness | C | Mn | P | S | Si | Cr | Ni | Mo | B | CE | PCM |
| mm | max % | max % | max % | max % | max % | max % | max % | max % | max % | max | max |
| 6.0 – 20.0 | 0.30 | 1.60 | 0.025 | 0.010 | 0.70 | 1.50 | 1.50 | 0.70 | 0.004 | 0.60 | 0.41 |
| 21.0 – 40.0 | 0.30 | 1.60 | 0.025 | 0.010 | 0.70 | 1.50 | 1.50 | 0.70 | 0.004 | 0.65 | 0.43 |
| 41.0 – 50.0 | 0.30 | 1.60 | 0.025 | 0.010 | 0.70 | 1.50 | 1.50 | 0.70 | 0.004 | 0.74 | 0.48 |
Mechanical Properties for Rockstar 500 High Tensile Plate
| 450-540 BHN (On a milled surface 0.5-2 mm below the plate surface | ||||
| Hardness | Yield Strength (MPa) | Tensile Strength (MPa) | % Elongation (L0=50 mm) | Impact at -20°C (In Joules) |
| Typical values for 15 mm plate thickness | 1250 | 1500 | 8 | 27 |
Makes of Rockstar 500 Hardness Plate Country Origin
| Brand | Manufacture/Co | Country | Hardness Range |
| Value for Rockstar 500 BHN | |||
| Rockstar 500 | Essar Steel India Ltd. | India | 450-540 |
EN 10029 EN 10051 Rockstar 500 Plate Processing
The majority of normal processing can be performed on Rockstar 500 plate
- Cutting
- Forming Drilling/ Machining
- Grinding
- Testing
Rockstar 500 Abrasion Resistant Plates Available Sizes
| 1/8" | 3/8" | 3/4" | 1-1/2" | 3" |
| 3/16" | 1/2" | 1" | 2" | 4" |
| 1/4" | 5/8" | 1-1/4" | 2-1/2" | |
| *1/8" thick plate is available in
one size only 60"x 120". The 3/6" thick plate is available only as 48" x 144" and 96" x 144". |
||||
Rockstar 500 BHN Plates Available Thickness, Widths and Lengths
|
Thickness
|
Width
|
Length
|
|
4
|
2000
|
6000
|
|
5
|
2000
|
6000
|
|
6
|
2000
|
6000
|
|
6
|
2500
|
6000
|
|
8
|
2000
|
6000
|
|
8
|
2500
|
6000
|
|
10
|
2000
|
6000
|
|
12
|
2000
|
6000
|
|
15
|
2000
|
6000
|
|
16
|
2000
|
6000
|
|
20
|
2000
|
6000
|
|
25
|
2000
|
6000
|
|
32
|
2000
|
6000
|
|
40
|
2000
|
6000
|
|
50
|
2000
|
6000
|
|
60
|
1800
|
3400
|
$ Price Of Rockstar 500 Wear Resistance Plates
- Rockstar 500 Hot Rolled Steel plate Stockyard
US / Metric Ton (FOB Price) on request - High Quality Rockstar 500 Plates
US / Metric Ton (FOB Price on request - Rockstar 500 Stone Crusher Liner Plates Stockists
US / Metric Ton (FOB Price) on request - EN 10051 Rockstar 500 Wear Resistant Plates
US / Ton (FOB Price) on request - Rockstar 500 structural steel Plate Stockholders
US / Ton (FOB Price) on request - Rockstar 500 Cold Forming Steel Plates stocks
US / Metric Ton (FOB Price) on request
Rockstar 500 Plates Application Industries
Some of the key applications are :
- Screen Plates - Chute Liners
- Conveyor Buckets
- Cutting Edges
- Ripper Tyne
- Hoppers
- Ore Scrapers
- Slide conveyor
- Dump trucks
- Slurry Pipe Systems
Other Types Of Rockstar 500 Plates
Rockstar 500 Stockholders, Rockstar 500 Plates stockyard, High Strength Rockstar 500 Plate Stocks, Rockstar 500 Abrasion Resistant Weldable Steel Plates, Rockstar 500 Wear Plates Suppliers, EN 10051 Rockstar 500 Plates Exporters, Rockstar 500 Hardness Plates, Rockstar 500 importers, Abrasion resistant Rockstar 500 Steel Plate Dealers, Low-Temperature Rockstar 500 Steel Plates Traders, Rockstar 500LT plates Manufactures, Rockstar 500 quenched and tempered steel plate inventory, Rockstar 500 Stone Crusher Liner Plates wholesaler, Rockstar 500BHN Plates, Essar Rockstar 500 Abrasion Resistant Steel Plates, Essar Steel Make Rockstar 500 Plate, Rockstar 500 HBW, Rockstar 500 Brinell plate Stockists in Mumbai India
