EN 10149-2 Grade S550MC Plates

S550 MC EN 10149-2 cold forming structural steel Plates

S550MC Plates, EN 10149-2 Steel plate, S550 MC EN 10149-2 structural steel Plates, ASTM A514 High yield EN10149-2 Grade S550MC cold-forming Plates, PERFORM 550 Heavy Steel Plates Exporters, Suppliers and Stockists in India.

We at Champak steel trade, manufacture and supply EN 10149-2 Grade: S550MC plates. We have a range of products that are quality tested and offer amazing usability.

Our S700MC plates are structural steels developed for applications that require high yield strength. It can be used in many load bearing applications for its high yield. The steel is widely used in cold pressed parts and sections. S700 bears amazing welding and forming properties. The strength that if offers makes it usable in steel frames, pipes and load bearing beams. Our products are available to our customers in customizable options to meet their specific requirements.

We have a highly equipped infrastructure facility where we develop products that are reliable and offer maximum utility.

EN10149 -2 S550MC High Strength Steel Plates, S550MC W. Nr.1.8974 Hot-Rolled plates Stockholders, BS 75F70 S550 MC EN EN10149 -2 structural steel Plate Dealers & Distributors in Mumbai.



EN10149 -2 S550MC Plates Specification :

Thickness : 2 - 10 mm
Width : Up to 1600 mm
Length : Up to 16000 mm
Grade : S355MC, S420MC, S460MC, S460MC, S550MC, S650MC, S700MC, ALFORM, PERFORM

Chemical Composition of EN S550MC steel,by %

Content % (ladle analysis), maximum
Grade C % max Mn % max Si % max P % max S % max Alges % min Nb % max V % max Ti % max Mo % max B % max
S550MC 0.12 1.90 0.50 0.025 0.015 0.015 0.09 0.20 0.22 0.50 0.005

Mechanical properties According to EN10149-2 High Tensile Plate

Grade Yield strength ReH1)
N/mm² min.
Tensile strength Rm1)
N/mm²
Elongation at break A1) % min. Bending test(180°)
Nominal thickness mm Bent stem diameter min. ²)
<3
Lo = 80mm
≥3
Lo = 5.65 √So
S550MC 550 650~820 11 13 1.5 t

High Yield EN 10149-2 Grade : S550MC structural Steel Plate Processing

The majority of normal processing can be performed on EN 10149-2 S550MC plate

  • Cutting
  • Forming Drilling/ Machining
  • Grinding
  • Testing

$ Price Of EN 10149-2 S550 MC Heavy Steel Plates

EN 10149-2 S550MC Plates Application Industries

Some of the key applications are :

  • Bulldozer Blades
  • in Bridges & Building
  • Quarry Trucks
  • Articulated Dump Trucks
  • Oilfield Fabrications
  • Hydraulic Systems
  • Buckets
  • Mechanical Handling
  • Waste Compaction Equipment
